----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 47
11.4. ) DEFAULT CVMk CONFIGURATION : 00 / 9.600 / 7 bits / N / 1 bit
- Available baud rates: 2.400 - 4.800 - 9.600 - 19.200 bauds
- CVM / RS-485 module: DB-9 - Male connector
Nr. pin Signal
1 c ------ TX --
2 d ------ TX +
5 g ------ GND
- CVM/ RS-232 module: RS-232 cable ( CVMk ---------- PC - DB-9)
