----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 31
10.1. ADDITIONAL SCREEN WITH THE RELAY OUTPUT MODULES
Relay modules: CVM-ERC-1 (1 relay ), CVM-ERC-2 ( 2 relays ),
CVM-ERC420-1 ( 1 relay + 1 analog output) or the CVM-RED-C2 ( 2 outputs ).
With this modules the CVMk - can be configured for:
A.- Pulse every certain kW.h or kvar.h (ENERGY). You can define the value
corresponding to the energy consumed for generating a pulse (0.5 sec. long): kW.h
/ 1 pulse or kvar.h / 1 pulse
B.- ALARM conditions: the parameter to be controlled, the maximum value, the
minimum value and the "delay" are programmed for each relay output.
----------------------------------------------------------------------------------
On the CVMk screen following messages appear at this SET-UP point (provided
the right module is connected to the equipment):
OUT 1 RELAY 1
CODE
00
( Parameter Nr. (1)
)
Depending on the selected variable we will pass to a.- or b.- sections
; In case that no parameter is wanted to be programmed set par. Nr. = 00.
