----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 44
11.2.4. MAXIMUM POWER DEMAND COMMANDS
COM.
CONCEPT QUESTION ANSWER
RPE
Read power demand period + param.
( kW=21, KVA=26 or AIII=20 )
$pp RPE ch
$pp 2 x 2 digits ch
WPE
Write power demand period (2 dig.) +
param. (kW=21, kVA=26, AIII=20 )
$pp WPEXXXXch
$pp ACK ch
CMD
Delete maximum demand value pd=0
$pp CMD ch
$pp ACK ch
RMD
Read maximum demand value:
DATE, MAXIMUM (from the last reset),
LAST PERIOD MAXIMUM
$pp RMD ch
$pp 35 digits ch
xx/xx/xx xx:xx:xx
xxxxxxxxx (9 dig)
xxxxxxxxx (9 dig)
11.2.5. COMMAND to read all the CVMk parameters
COMMAND CONCEPT QUESTION ANSWER SIZE
RAL
Read TOTAL
$pp RAL ch
$pp + 244 bytes + ch
With this parameter all the parameters are requested: 30 x 8 bytes in hexa-ASCII
format in the following order:
[ 0 ] L12 [ 1 ] L23 [ 2 ] L31 [ 3 ] Av Voltage phase-phase
[ 4 ] L1 [ 5 ] L2 [ 6 ] L3 [ 7 ] Av Voltage phase-neutral
[ 8 ] L1 [ 9 ] L2 [ 10 ] L3 [ 11 ] Av Current
[ 12 ] L1 [ 13 ] L2 [ 14 ] L3 [ 15 ] III Active power
[ 16 ] L1 [ 17 ] L2 [ 18 ] L3 [ 19 ] III Inductive power
[ 20 ] L1 [ 21 ] L2 [ 22 ] L3 [ 23 ] III Capacitive power
[ 24 ] L1 [ 25 ] L2 [ 26 ] L3 [ 27 ] Av Power factor
[ 28 ] Frequency
[ 29 ] III Apparent power
- 2 bytes : current units 00 - mA / 01 - A
- 2 bytes : power units 00 - W / 01 - kW
(*) - Power factor ( x 100 ) : When is capacitive it adds 200
0 ---------------------------- 100 --------------------------- 200
+0.0 Ind. 1.0 Cap. -0.00
