----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 7
3. INSTALLATION AND STARTUP
The manual you hold in your hands contains information and warnings that the user
should respect in order to guarantee a proper operation of all the instrument
functions and keep its safety conditions.
The instrument must not be powered and used until its definitive assembly on the
cabinet’s door.
Whether the instrument is not used as manufacturer’s specifications, the
protection of the instrument can be damaged.
When any protection failure is suspected to exist (for example, it presents external
visible damages), the instrument must be immediately powered off. In this case
contact a qualified service representative.
3.1. INSTALLATION
Before applying AC power to the, check following points :
a.- Supply voltage : see rear part of your CVMk
According CVMk model:
a.1.- CVMk .... : - Power supply Vac ( Single phase ) 50 ...60 Hz
230 V a.c. or 400 V a.c.
240 V a.c. or 480 V a.c.
110 V c.a.
- Frequency : 50 ... 60 Hz
- Supply tolerance : + 10 % / --15 %
- Connection terminals : Terminals 1 - 2 - 3 .
- Instrument burden : 3 VA
