----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 46
11.3. EXAMPLES
SEND : $00RFI65 [ LF] ( Power factor)
RECEIVED : $00083083084083F1[ LF]
($00, PF1= 083 , PF2= 083 , PF3= 084 = 0.84 ind , Pavg = 0.83)
SEND : $00RVI75 [LF]
RECEIVED : $0000000021900000012100000010300000014865 [LF]
$00, V1 = 000000219 = 219 V V2 = 000000121 = 121 V
V3 = 000000103 = 103 V Vavg = 000000148 = 148 V
SEND : $00RRT7C [LF] ( V / A ratio )
RECEIVED : $000250001100050032 [LF]
$00, Voltage primary = 025000 = 25.000 (6 digits).
Voltage secondary = 110 = 110 (3 digits).
Current primary = 00500 = 500 (5 digits).
SEND : $00RRS7B [LF] (Communication)
RECEIVED: $00000719600480017 [LF]
$00, Peripheral number = 00
Parity = 0 = Non (1 dig.)
Bits = 7 (1 dig.)
Stop bits = 1 (1 dig.)
Baud rate = 9600 (4 dig.) (COM1)
2ª Baud rate = 4800 (4 dig.) (COM2 - RED module)
SEND : $00RAI60 [LF]
RECEIVED : $0000021400000019000000018500000019600073 [LF]
$00, A1= 000214000 = 214000 mA = 214 A
A2= 000190000 = 190000 mA = 190 A
A3= 000185000 = 185000 mA = 185 A
Am =000196000 = 196000 mA = 196 A
