----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 21
NOTES:
- The maximum programmable value is 10.000
- The secondary of the current transformers is not programmable. It is automatically
taken as 5 A (... / 5 A ac)
5.5. Parameter SETUP
The 6 additional parameters that we like to see on the screen have to be selected in
this option.
- SECOND PAGE setup: This option is identified with the lighting on of the three
green leds.
- THIRD PAGE setup: This option is identified with the lighting on of the three yellow
leds.
- -
- -
- -
Each display has two digits to select the desired parameters among the ones in the
attached code chart.
Once the parameters have been programmed we can place the corresponding
sticking labels.
