----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 4
2. MAIN CHARACTERISTICS
The CVMk power meter is a programmable measuring instrument, offering several
operation possibilities selectable in its SETUP option. Before power supplying the
instrument, read the CONNECTIONS and SETUP sections and choose the most
suitable operation mode for getting your desired data.
The CVMk is an instrument which measures, calculates and displays all the main
electrical parameters at any electrical network (balanced or not). The measuring is
true RMS value, through three a.c. Voltage inputs and three a.c. Current inputs (from
Current Transformers .../ 5A).
By means of an internal microprocessor it simultaneously measures:
parameter L1 L2 L3 Average Addition
Voltage (phase-neutral) x x x x
Voltage (phase-phase) x x x x
Current x x x x
Active power x x x x
Reactive power L x x x x
Reactive power C x x x x
Power factor x x x x
Apparent power x
Frequency x
