----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 45
11.2.6. COMMANDSFOR THE CONFIGURATION OF THE RELAY
MODULES
COM.
CONCEPT QUESTION ANSWER
RCC
Read
configuration
(W.h or kvar.h)
$pp RCC ch
$pp 22 digits ch
arg : code channel 1 param. (2 dig) + value1
(9 dig)+code channel 2 param.+value2 (9 dig)
WCC
Write module
configuration
(W.h or kvar.h)
$pp WCC13 digits ch
argument : channel number (2 dig) +
parameter code (2 dig) + value (9 dig)
$pp ACK ch
ALARM CONFIGURATION : parameter + maximum + minimum + delay
RCA
Read alarm
configuration
2 relays
$pp RCA ch
$pp 2 x 25 digits ch
argument: parameter 1 code (2 dig) + maximum
value 1 (9 dig) +minimum value 1 (9 dig) + delay
(4 dig) + relay status (1 dig)
WCA
Write module
configuration
$pp WCA 26 digits ch
argument: channel number (2 dig) +
parameter code (2 dig)+maximum value
(9 dig) +mín v. (9 dig.) + delay (4 dig)
$pp ACK ch
11.2.7. COMMANDS FOR THE CONFIGURATION OF THE 4 - 20 mA
MODULES
COM.
CONCEPT QUESTION ANSWER
RDA
Read configuration
$pp RDA ch
$pp 2 x 13 digits ch
argument: mode 0-20 mA/ 4 - 20 mA (2 dig)
+parameter code (2 dig) + offset value (9 dig)
RFE
Read full scale
$pp RFE ch
$pp 9 digits channel 1 + 9 dig. channel 2 ch
WDA
Write module
configuration
$pp WDA 24 digits ch
argument: channel number (2 dig) +
mode 0-20 mA/ 4 - 20 mA (2 dig) + parameter
code (2 dig) + offset value
(9 dig) + full scale ( 9 dig.)
$pp ACK ch
