----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 28
Mechanical Characteristics :
Installation ................................ Panel mounting
Connection ............................... Fixed connection terminal
Protection ................................. IP-41
Dimensions ............................... 144 x 144 mm (DIN 43 700)
Weight ..................................... 0.75 kg
7. SAFETY CONSIDERATIONS
All installation specification described at the previous chapters named
INSTALLATION AND STARTUP, INSTALLATION MODES and SPECIFICATIONS.
Note that with the instrument powered on, the terminals could be dangerous to
touching and cover opening actions or elements removal may allow accessing
dangerous parts. This instrument is factory-shipped at proper operation condition.
8. MAINTENANCE
The CVMk does not require any special maintenance. No adjustment, maintenance
or repairing action should be done over the instrument open and powered and,
should those actions are essential, high-qualified operators must perform them.
Before any adjustment, replacement, maintenance or repairing operation is carried
out, the instrument must be disconnected from any power supply source.
When any protection failure is suspected to exist, the instrument must be
immediately put our of service. The instrument’s design allow a quick replacement in
case of any failure.
