Instruction Manual
Wibeee
If it takes longer than 2 minutes, it is recommended to return to the initial state, check the Wi-Fi
coverage and re-start the process.
If it is unable to connect to the Wi-Fi, the device retries 5 times. If the lack of connection per-
sists, it goes into Congurationmode(sothatthecongurationcanbechangedwithoutopen-
ing the panel) for 5 minutes; it then tries to reconnect again and, until it manages to reconnect,
it remains in this alternating mode. (5 minutes in the Conguration state and 1 attempt to
connect).
3�- Connecting state
Blue LED→Fastblinkinglight(<1s)
Red LED→Slowblinkinglight(1s)
Inthisstate,thedevicehasconnectedtotheWi-Finetworkandiswaitingtocompletetherst
successful transfer of data.
Whenitrstmanagestosuccessfullysenddata,itwillenterthe“Connected and sending OK”
state.
Ifthedeviceisnotabletosuccessfullysendtherstsetofdata,itwillretry3times.Ifitdoesnot
manage to send it, the Wi-Fi connection is restarted and it retries sending the package 3 times.
Itremainsinthisstateuntiltherstdataissuccessfullysent.
4�- Connected and sending OK state
Blue LED→Steadylight.
Red LED→Slowblinkinglight(1s)
When the device is congured and connected to the network in the user's infrastructure, it
automatically starts sending data on the installation's power consumption to the server (every
minute).
It also allows you to access instant measurements by making requests to its internal XML and
Modbus servers.
