Cisco 2600 Series Hardware Installation Guide

2-6
Cisco 2600 Series Routers Hardware Installation Guide
OL-2171-02
Chapter 2 Preparing to Install the Router
Preparing to Connect to a Network
• 100BASE-T—2-pair Category 5 or unshielded twisted-pair (UTP) straight-through RJ-45 cable.
• 10BASE2—Ethernet on thin coaxial cable, also known as thin Ethernet. The maximum segment
distance is 607 feet (186 meters).
• 10BASE5—Ethernet on thick coaxial cable, also known as thick Ethernet. The maximum segment
distance is 1,640 feet (500 meters).
• 10BASE-T—Ethernet on UTP cable. The maximum segment distance is 328 feet (100 meters). UTP
cables look like the wiring used for ordinary telephones; however, UTP cables meet certain
electrical standards that telephone cables do not meet.
Table 2-1 lists the router models described in this guide and summarizes the LAN interfaces supported
on each model.
Token Ring Connections
The Cisco 2612 provides both an Ethernet interface and a Token Ring shielded UTP interface. The
Cisco 2613 provides a single Token Ring interface. (See Table 2-1.)
The IEEE has established Token Ring as standard IEEE 802.5. Specifications indicate a maximum
segment distance of 328 feet (100 meters) for UTP cabling.
Note To ensure agency compliance with FCC Class B electromagnetic emissions requirements (EMI),
make sure that you use the shielded RJ-45 Token Ring cable when connecting your router to your
Token Ring network.
Table 2-1 Cisco 2600 Series LAN Connections
Model
Ethernet
(10BASE-T)
Token Ring
(RJ-45)
Fast Ethernet
(10/100)
Network
Module Slot
WAN Interface
Card Slots
Advanced
Integration
Module Slots
Cisco26101——121
Cisco2610XM——1121
Cisco26112——121
Cisco2611XM——2121
Cisco261211—121
Cisco2613—1—121
Cisco2620——1121
Cisco2620XM——1121
Cisco2621——2121
Cisco2621XM——2121
Cisco 2650——1121
Cisco2650XM——1121
Cisco 2651——2121
Cisco2651XM——2121
Cisco2691——2132
