Page #58 background image
4-2
Cisco 2600 Series Routers Hardware Installation Guide
OL-2171-02
Chapter 4 Installing a Network Module or Interface Card
Step 1 Turn OFF electrical power to the router. Do NOT unplug the power cable. If the router uses a DC power
supply, remove power from the DC circuit with the following steps:
a. Locate the circuit breaker on the panel board that services the DC circuit.
b. Switch the circuit breaker to the OFF position.
c. Tape the switch handle of the circuit breaker in the OFF position.
Step 2 Remove all network cables, including telephone cables, from the rear panel of the router.
Caution Network modules are not hot-swappable. To avoid damaging the module, turn OFF electrical power
to the chassis and disconnect all network cables, including telephone cables, before inserting or
removing a network module.
Step 3 Attach an ESD-preventive wrist strap before handling the card, and connect the wrist strap to an
electrical ground.
Step 4 Using a number 1 Phillips screwdriver, remove the blank filler panel from the chassis slot. Save the
blank filler panel for future use.
Step 5 Align the network module with the guides in the chassis and slide it gently into the slot.
Step 6 Slide the module into place until the edge connector is securely seated in the connector on the
motherboard.
Step 7 Using the number 1 Phillips screwdriver, tighten the module’s captive mounting screws.
Step 8 Reinstall blank panels to fill any unoccupied chassis slots.
Caution To provide proper airflow, install the blank panels shipped with the router in any empty chassis slots.
Step 9 Plug in the network interface cables and turn ON power to the router. For a router using a DC power
supply, remove the tape from the circuit breaker and turn the circuit breaker to the ON position.
Installing a WAN Interface Card
Warning
Before installing a WAN interface card into the network module, turn OFF electrical power to the
router to avoid the risk of electrical shock to yourself or to the equipment. To see translations of
the warnings that appear in this publication, refer to the Regulatory Compliance and Safety
Information document that accompanied this device.
The following tools are required or recommended for this task:
ESD-preventive wrist strap
Number 1 Phillips screwdriver
Duct or electrical tape (for routers using a DC power supply only)
