3-61
Software Configuration Guide for Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers
OL-1957-04
Chapter3 Configuring with the Command-Line Interface
Configuring 1-Port G.SHDSL WAN Interface Card
Step7
Router(config-if-vc)#
encapsulation {aal1 | aal2 |
aal5ciscoppp | aal5mux |
aal5nlpid | aal5snap}
(Optional) Configures the ATM adaptation layer (AAL)
and encapsulation type.
• aal1—AAL1
• aal2—AAL2
• aal5ciscoppp—Cisco PPP over AAL5
• aal5mux—AAL5+MUX
• aal5nlpid—AAL5+NLPID
• aal5snap—AAL5+LLC/SNAP (the default)
Step8
Router(config-if-vc)# exit
Exits from interface-atm-vc configuration mode.
Step9
Router(config-if)# dsl
operating-mode {gshdsl
symmetric annex {A | B}
Configures the DSL interface to operate in a specified
DSL mode:
• gshdsl—Configures multirate, high-speed DSL per
ITU G.991.2
• symmetric—Configures symmetrical mode per
• ITU G.992.1.
• annex—Configures the regional operating
parameters.
• A—Sets the operating parameters for
North America. This value is the default.
• B—Sets the operating parameters for Europe.
The default is gshdsl symmetric annex A
Step10
Router(config-if)#
equipment-type {co | cpe}
Configures the DSL interface to function as central
office equipment or customer premises equipment:
• co—The WIC functions as central office equipment
and can interface with another G.SHDSL WIC
configured as cpe.
• cpe—The WIC functions as customer premises
equipment and can interface with a DSLAM or with
another G.SHDSL WIC configured as co.
The default is cpe.
Step11
Router(config-if)# dsl linerate
{kbps | auto }
Configures the DSL line rate:
• kbps—Line rate (data transfer rate) in kilobits per
second. Allowable entries are 72, 136, 200, 264,
392, 520, 776, 1032, 1160, 1544, 2056, and 2312.
• auto—The WIC automatically trains for an optimal
line rate by negotiating with the far-end DSLAM or
WIC.
The default is auto.
Step12
Router(config-if)# exit
Exits from ATM interface configuration mode.
Step13
Router(config)# exit
Exits from global configuration mode.
Command Purpose
