2-2
Software Configuration Guide for Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers
OL-1957-04
Chapter2 Using the Setup Command Facility
Using the setup Command Facility
Using the setup Command Facility
The setup command facility displays from your PC terminal emulation program window.
To create a basic configuration for your router, do the following:
• Complete the steps in the “Configuring Global Parameters” section on page2-2.
• Complete the steps in the “Configuring Interface Parameters” section on page2-5 that apply to your
router and network.
• Complete the steps in the “Completing the Configuration” section on page2-23.
Note If you make a mistake while using the setup command facility, you can exit and run the facility again.
Press Ctrl-c, and type setup at the enable mode prompt (2600#).
Configuring Global Parameters
Step1 Power on the router. The power switch is on the rear panel of the router, at the lower right corner, near
the power cord.
Messages will begin to appear in your terminal emulation program window.
Caution Do not press any keys on the keyboard until the messages stop. Any keys pressed during this time are
interpreted as the first command typed when the messages stop, which might cause the router to power
off and start over. It takes a few minutes for the messages to stop.
The messages look similar to the following:
Note The messages vary, depending on the CiscoIOS software release, interface modules in place in
your router, and feature set you select. The screen displays in this section are for reference only
and might not exactly reflect the messages on your console.
System Bootstrap, Version 11.3(1)XA, PLATFORM SPECIFIC RELEASE SOFTWARE (fc1)
Copyright (c) 1998 by cisco Systems, Inc.
C2600 platform with 32768 Kbytes of main memory
rommon 1 b f
program load complete, entry point: 0x80008000, size: 0xef4e0
Self decompressing the image : ###############################################
[OK]
Notice: NVRAM invalid, possibly due to write erase.
program load complete, entry point: 0x80008000, size: 0x415b20
Self decompressing the image :
##########################################################################################
##########################################################################################
##########################################################################################
###############[OK]
Restricted Rights Legend
