Cisco 2620 User Manual

3-21
Software Configuration Guide for Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers
OL-1957-04
Chapter3 Configuring with the Command-Line Interface
Configuring ATM Interfaces
Configuring SVCs
To configure the ATM interface with switched virtual circuits (SVCs), follow this procedure:
Step7
Router(config-if)# pvc 0/100
Configure a new ATM PVC. Enter
interface-ATM-VC configuration mode. The PVC
command has the format pvc [name] vpi/vci
[ilmi|qsaal] You have entered interface-ATM-VC
configuration mode when the prompt changes to
Router(config-if-atm-vc).
Step8
Router(config-if-atm-vc)# protocol ip
200.200.200.2 broadcast
Map the PVC to an address.
Step9
Router(config-if-atm-vc)# exit
Exit back to global configuration mode.
Repeat Step 4 through Step 8 if your router has
more than one interface that you need to
configure.
Step10
Router(config)# Ctrl-z
When you finish configuring interfaces, return to
enable mode.
Command Purpose
Command Purpose
Step1
Router> enable
Password: password
Router#
Enter enable mode. Enter the password.
You have entered enable mode when the prompt
changes to Router#.
Step2
Router# configure terminal
Enter configuration commands, one per line.
End with CNTL/Z.
Router(config)#
Enter global configuration mode. You have
entered global configuration mode when the
prompt changes to Router(config)#.
Step3
Router# ip routing
Router# appletalk routing
Router# ipx routing
Enable routing protocols as required for your
global configuration. This example uses IP
routing, AppleTalk routing, and Internetwork
Packet Exchange (IPX) routing.
Step4
Router(config)# interface atm 1/0
Router(config-if)#
Enter interface configuration mode. You have
entered interface configuration mode when the
prompt changes to Router(config-if)#.
Step5
Router(config-if)# pvc 0/5 qsaal
Configure a signaling channel for the SVC.
Step6
Router(config-if-atm-vc)# exit
Exit back to interface configuration mode.
Step7
Router(config-if)# pvc 0/6 ilmi
Configure additional signaling channels for the
SVC.
Step8
Router(config-if-atm-vc)# exit
Exit back to interface configuration mode.
Step9
Router(config-if)# ip address 192.168.74.3
255.255.255.0
Assign an IP address and subnet mask to the
interface.
