3-16
Software Configuration Guide for Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers
OL-1957-04
Chapter3 Configuring with the Command-Line Interface
Configuring T1 and E1 Interfaces
Configuring E1 Interfaces
Use the following procedure to configure a new E1 or CE1/PRI interface (balanced or unbalanced) or to
change the configuration of an existing interface.
Configuring TDM Connect (Data Pass-Through)
For multiflex trunk interfaces using the time-division multiplexing (TDM) connect function, you can use
the connect command to connect two groups of DS0 timeslots from two controllers.
Command Purpose
Step1
Router> enable
Password: password
Router#
Enter enable mode. Enter the password.
You have entered enable mode when the prompt
changes to Router#.
Step2
Router# configure terminal
Enter configuration commands, one per line.
End with CNTL/Z.
Router(config)#
Enter global configuration mode. You have
entered global configuration mode when the
prompt changes to Router(config)#.
Step3
Router# ip routing
Router# appletalk routing
Router# ipx routing
Enable routing protocols as required for your
global configuration. This example uses IP
routing, AppleTalk routing, and Internetwork
Packet Exchange (IPX) routing.
Step4
Router(config)# controller e1 1/0
Select the CE1/PRI interface to configure. This
example configures an E1 interface in slot 1 and
unit 0.
Step5
Router(config-controller)# framing crc4
Specify the framing type.
Step6
Router(config-controller)# linecode hdb3
Specify the line code format.
Step7
Router(config-controller)# channel-group 0
timeslots 1,3-5,7
Specify the channel group and time slots to be
mapped. For multiflex trunk interfaces, only
channel 0 can be configured.
Step8
Router(config-controller)# interface
serial
1/0:0
Configure each channel group as a virtual serial
interface. Specify the E1 interface, unit number,
and channel group to modify.
Step9
Router(config-if)# ip address 10.1.15.1
255.255.255.0
Assign an IP address and subnet mask to the
interface.
Step10
Router(config-if)# appletalk static
cable-range 3-3
Router(config-if)# appletalk zone ZZEth
Router(config-if)# ipx network B005
Configure routing protocols on the interface. You
must have previously enabled these protocols as
part of global configuration. In this example,
AppleTalk and IPX are being configured on the
interface.
Step11
Router(config-if)# exit
Exit back to global configuration mode.
Return to Step 4 if your router has more than one
CE1/PRI interface that you need to configure.
Step12
Router(config)# Ctrl-z
When you finish configuring interfaces, return to
enable mode.
