Software Configuration Guide for Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers
OL-1957-04
Chapter2 Using the Setup Command Facility
Configuring Interface Parameters
Token Ring Interface Configuration
This section contains a sample configuration for the Token Ring interface. Enter the values appropriate
for your router and network. The messages you see may vary.
Do you want to configure TokenRing0/0 interface? [yes]:
Tokenring ring speed (4 or 16)? [16]:
Configure IP on this interface? [yes]:
IP address for this interface: 1.0.0.1
Subnet mask for this interface [255.0.0.0]:
Class A network is 1.0.0.0, 8 subnet bits; mask is /8
Configure IPX on this interface? [no]: y
IPX network number [1]:
Need to select encapsulation type
[0] sap (IEEE 802.2)
[1] snap (IEEE 802.2 SNAP)
Enter the encapsulation type [0]:
Serial Interface Configuration
This section contains a sample configuration for the 1- or 2-port serial interface. Enter the values
appropriate for your router and network. The messages you see may vary.
Do you want to configure Serial0/0 interface? [yes]:
Some encapsulations supported are
ppp/hdlc/frame-relay/lapb/atm-dxi/smds/x25
Choose encapsulation type [ppp]:
Note The following sections describe the prompts for each encapsulation type. For PPP and HDLC
encapsulation, no further configuration is needed.
No serial cable seen.
Choose mode from (dce/dte) [dte]:
Note If no cable is plugged in to your router, you need to indicate whether the interface is to be used as DTE
or DCE. If a cable is present, the setup command facility determines the DTE/DCE status. If the serial
cable is DCE, you see the following prompt:
Serial interface needs clock rate to be set in dce mode.
The following clock rates are supported on the serial interface.
0
1200, 2400, 4800, 9600, 19200, 38400
56000, 64000, 72000, 125000, 148000, 500000
800000, 1000000, 1300000, 2000000, 4000000, 8000000
Choose clock rate from above: [2000000]:
Configure IP on this interface? [yes]:
IP address for this interface: 2.0.0.1
Subnet mask for this interface [255.0.0.0]:
Class A network is 2.0.0.0, 8 subnet bits; mask is /8
Configure IPX on this interface? [no]: yes
IPX network number [8]:
