Hardware Installation Guide for the Cisco 4451-X Integrated Services Router
OL-27644-01
Organization
This guide includes the following chapters:
Chapter Title Description
1 Overview of the Cisco 4451-X
Integrated Services Router
Describes the router chassis views, information
for locating the serial number, PID
1
, and UDI
2
.
Also includes general hardware features, slot,
port, and interface information; and LED
indicators.
2 Preparing for Router Installation Describes site requirements and the equipment
needed to install the router.
3 Installing and Connecting the Router Describes how to install and connect the router to
LAN, WAN, and Voice networks.
4 Initial Configuration Describes how to power up the router and
perform the initial configuration.
5 ROM Monitor Overview and Basic
Procedures
Provides an overview of ROM Monitor concepts
and operations.
6 Installing and Upgrading Internal
Modules and FRUs
Describes how to install and upgrade internal
modules and field replaceable units
3
on the
router.
7 Online Insertion and Removal (OIR)
and Hot-Swapping
Describes how to remove and replace data and
modules using the online insertion and removal
4
procedure.
1. PID = Product ID
2. UDI = Universal Device Identifier
3. FRU = Field Replaceable Unit
4. OIR = Online Insertion and Removal

Cisco 4451-X Specifications

General

Aggregate Throughput	2 Gbps
Total Onboard WAN or LAN 10/100/1000 Ports	4
RJ-45-based Ports	4
SFP-based Ports	4
Enhanced Service Module (SM-X) Slots	2
NIM (Network Interface Module) Slots	3
Onboard ISC Slot	1
Memory (DRAM) Default	4 GB
Memory (DRAM) Maximum	16 GB
Flash Memory	8 GB
Rack Height	2 RU
Product Type	Router
Form Factor	Rack-mountable
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Product Series	Cisco 4000 Series
Model	4451-X
Network/Transport Protocol	IPsec
Remote Management Protocol	SNMP
Features	Firewall protection, VPN support, Quality of Service (QoS), IPv6 support
Interfaces	4 x 10/100/1000 Ethernet ports, 4 x SFP ports
Power	AC 100-240 V (50/60 Hz)
Memory	4 GB
Operating Temperature	0 to 40 °C
Storage Temperature	-40 to 70 °C
Humidity	5% to 95% non-condensing
