Chapter 3 Installing and Connecting the Router
Installing the Router
Figure 3-5 Mounting the Chassis in a Rack (Typical)
Figure 3-6 shows an installation with a chassis rear-forward.
Figure 3-6 Mounting the Chassis in a Rack, Rear Forward
Grounding the Chassis
After the router is installed, you must connect the chassis to a reliable earth ground. For the chassis
ground connection procedures, see the “Chassis Grounding” section on page 3-11.
1 Mounting screws (4)
302994
PS
1
1 Mounting screws (4)
