7-15
Firepower 7000 and 8000 Series Installation Guide
Chapter 7 Hardware Specifications
Firepower 7000 Series Devices
The following table describes the conditions under which the system status LEDs might be lit.
Table 7-24 Firepower 7115, 7125, and AMP7150 Front Panel LEDs
LED Description
NIC activity (1 and 2) Indicates whether there is any network activity:
• A green light indicates there is network activity.
• No light indicates there is no network activity.
System status Indicates the system status:
• No light indicates the system is operating normally, or is powered off.
• A red light indicates a system error.
See the Table 7-25Firepower 7115, 7125, and AMP7150 System Status, page 7-16 for more
information.
Reset button Allows you to reboot the appliance without disconnecting it from the power supply.
Hard drive activity Indicates the hard drive status:
• A blinking green light indicates the fixed disk drive is active.
• An amber light indicates a fixed disk drive fault.
• If the light is off, there is no drive activity or the system is powered off.
System ID Helps identify a system installed in a high-density rack with other similar systems:
• A blue light indicates the ID button is pressed and a blue light is on at the rear of the
appliance.
• No light indicates the ID button is not pressed.
Power button and LED Indicates whether the appliance has power:
• A green light indicates that the appliance has power and the system is on.
• A blinking green light indicates that the appliance has power and is shut down.
• No light indicates the system does not have power.
