Cisco 7941G User Manual

CHAPTER 2 Phone Installation 13
Phone Installation Overview 13
Cisco Unified IP Phone Cable Installation 13
Hookswitch Clip Removal (Required) 14
Adjust Handset Rest 15
Footstand Adjustment 15
Phone Cable Lock 16
TAPS Registration 16
Wired and Wireless Headsets 16
Headset Support 17
Audio Quality 17
Wireless Headset Selection (Cisco Unified IP Phone 7962G or 7942G) 17
CHAPTER 3 Calling Features 19
Calling Features Overview 19
Basic Call Options 19
Place Call 20
Place Call Using Speakerphone 20
Place Call Using Headset 20
Redial Number 21
Place Call When Another Call Is Active (Using Same Line) 21
Dial from Call Log 21
Additional Call Options 22
Place Call While Another Call is Active (Using Different Line) 22
Dial from Corporate Directory on Personal Computer Using Cisco WebDialer 22
Notify When Busy or Ringing Extension Available (CallBack) 23
Make Priority (Precedence) Call 23
Place Call Using Billing or Tracking Code 23
Make Call from Mobile Phone Using Mobile Voice Access 24
Place Call Using PAB 24
Make Speed Dial Call 24
Dial from Corporate Directory on Phone 25
Dial Personal Address Book (PAB) Entry 25
Make Fast Dial Call 25
Cisco Unified IP Phone 7941G, 7941G-GE, 7942, 7961G, 7961G-GE, and 7962 User Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
iv
Contents

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
