Cisco 7962 User Manual

Handset port6DC adaptor port1
Headset port7AC-to-DC power supply2
Footstand button8AC power cord3
Auxiliary port9Network port4
Access port5
Hookswitch Clip Removal (Required)
Some phones ship with a clip to secure the hookswitch. Before you use your phone, remove the hookswitch
clip (if present) from the cradle area. With the clip removed, the hookswitch lifts slightly when you pick up
the handset.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942, 7961G, 7961G-GE, and 7962 User Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
14
Phone Installation
Hookswitch Clip Removal (Required)

Cisco 7962 Specifications

General

Line Keys	6
Headset Jack	Dedicated headset port
Weight	3.5 lbs
Ethernet	10/100BASE-T Ethernet connection through 2-port switch
Protocol Support	SCCP, SIP
Power	IEEE 802.3af PoE
Speakerphone	Full-duplex speakerphone
Supported Codecs	G.711, G.729a, G.729ab, G.722
Display	320 x 222 pixel, 4-bit grayscale graphical LCD
Audio	Handset, headset, and speakerphone
