Guide bar and guide slot2

Guide rail and track3

Figure 87: Installing a Fabric Card

Insert fabric card top

guide rail into chassis top

fabric card guide rail.

2Chassis top fabric card

guide rail.

1

Hardware Installation Guide for Cisco 8800 Series Routers

123

Replace Chassis Components

Install a Fabric Card
