Cisco 8800 Series Hardware Installation Guide

Figure 92: Power Supply Bezel for 8804 Chassis
Replace DC Power Module
Follow these steps to remove a DC power module from the chassis.
Procedure
Step 1 Pull the handle down.
Step 2 Unscrew the screw that secures the power module using a Phillips screw driver.
Step 3 Slide the power module out of its bay while supporting it with your other hand to remove it.
Figure 93: DC Power Module
Step 4 Slide the new power module into the bay until it mates with its backplane connector.
Hardware Installation Guide for Cisco 8800 Series Routers
128
Replace Chassis Components
Replace DC Power Module
