Install screws from inside
the chassis to tighten each
screw to 26 in-lbs (2.93
N-m) of torque.
2Rear right rack mounting
bracket.
1
Figure 21: Attach 8808 Chassis to Rack - Rear Left View
Hardware Installation Guide for Cisco 8800 Series Routers
38
Unpack and Install the Chassis
Mount Chassis Into the Rack
