Step 7 Before you install the top hood, remove the connector cap from the alarm cable.
Figure 38: Remove Connector Cap
Step 8 Connect the alarm cable to the top hood.
Figure 39: Connect Alarm Cable
Door open alarm is supported in the chassis.
Note
Step 9 Position the top hood, with its brackets pointing down, above the cable management bracket screw holes.
Hardware Installation Guide for Cisco 8800 Series Routers
52
Unpack and Install the Chassis
Install Cable Management on a Chassis
