Openflow Mode for ASR9000
Openflow for the Cisco ASR 9000 Series router functions in the Integrated Hybrid mode. In this mode, both
Openflow and normal switching and routing (for layer 3) operations such as L2 ethernet switching, L3 routing,
etc are supported. Packets processed as the Openflow forwarding path can be processed as a normal forwarding
path.
OpenFlow Table Types
An OpenFlow flow table consists of a set of flows. Each flow contains a set of matches and actions. A table
has a set of capabilities in terms of supported matches and actions. Just like a policy-map, a table can be
applied to a set of targets but only in the ingress direction. Hence, OpenFlow matches and actions are applied
to the incoming traffic only.
A set of ordered tables is referred to as a pipeline. A pipeline may contain one or more ordered tables. An
OpenFlow pipeline of an OpenFlow switch on ASR9K supports only one flow table.
Note
Table 29: OpenFlow Table Types
DescriptionSupported InterfacesPipelineTable
Type
•
Supports L2 header matches.
•
Supports L2 actions.
•
Can be applied to the ingress L2 interfaces.
Bridge-domain, Gigabit
ethernet, Bundle,
Bundle-subinterfaces,
PWHE-subinterfaces
129L2
•
Supports L2 and L3 (IPv4/IPv6) header
matches.
•
Supports L2 actions.
•
Can be applied to the ingress L2 interfaces.
Bridge-domain, Gigabit
ethernet, Bundle,
Bundle-subinterfaces,
PWHE-subinterfaces
130L2_L3
•
Supports L3 (IPv4) header matches.
•
Supports L3 (IPv4) actions.
•
Can be applied to the ingress L3 interfaces.
VRF and global interfaces,
BVI (ipv4 only),
Bridge-domain, Gigabit
ethernet, Bundle,
Bundle-subinterfaces
131L3_V4
•
Supports L2 and L3 (IPv4/IPv6) header
matches.
•
Supports L3 (IPv4/IPv6) actions.
•
Can be applied to the ingress L3 interfaces.
VRF and global interfaces,
BVI, Bridge-domain,
Gigabit ethernet, Bundle,
Bundle-subinterfaces
132L3_DS
Cisco ASR 9000 Series Aggregation Services Router System Management Configuration Guide, Release 5.1.x
276
Implementing Open Flow Agent
About OpenFlow
