Cisco ASR 1004 Install Guide

7-29
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-09
Chapter 7 Cisco ASR 1004 Router Overview and Installation
Connecting a Terminal to the Cisco ASR Series 1000 Route Processor Console Port
Step 11 Switch the On/Off circuit breaker switch to the On (|) position.
This completes the procedure for connecting the –48 VDC power supply in the Cisco ASR 1004 Router.
Connecting a Terminal to the Cisco ASR Series 1000 Route
Processor Console Port
The Cisco ASR 1004 router processor has an asynchronous serial (EIA/TIA-232) RJ-45 console port
labeled CON on its front panel. You can connect this port to most types of video terminals through use
of the console cable kit that is included with your Cisco ASR 1004 Router. The console cable kit
contains:
• One RJ-45 to RJ-45 crossover cable
• One RJ-45 to DB-9 (female) adapter
A crossover cable reverses pin connections from one end to the other. In other words, it connects pin 1
(at one end) to pin 8 (at the other end), pin 2 to pin 7, pin 3 to pin 6, and so on. You can identify a
crossover cable by comparing the two modular ends of the cable. Hold the cable ends in your hand,
side-by-side, with the tabs at the back. Ensure that the wire connected to the outside (left) pin of the left
plug (pin 1) is the same color as the wire connected to the outside (right) pin of the right plug (pin 8).
Use the following procedure to connect a video terminal to the console port on a route processor.
Note Each Cisco ASR 1000 Series Route Processor 1 must have a console port connection (typically to a
terminal server) if you are running a redundant configuration in the chassis.
Figure 7-21 shows the route processor console port.
Figure 7-21 Cisco ASR 1004 Router ASR 1000 Series Route Processor Console Port
Step 1 Connect one end of the RJ-45 cables to the serial RJ-45 port (CON) on the Cisco ASR 1000 Series Route
Processor 1 (see Figure 7-21).
1 CON port connection 2 AUX port connection
MI
N
A
C
O
MA
J
STB
Y
A
C
T
V
S
TA
T
ASR100
0-R
P
1
P
WR
C
R
I
T
0
S
PA
-
4
X
O
C3
-
P
O
S
0
1
2
3
A
A
/
L
C/A
A
/L
C/A
A/L
S
PA
-4
X
O
C
3
-P
O
S
S
TATUS
0
1
2
3
C/
A
A
/L
C/A
A
/
L
C/A
A
/
L
C/A
A
/L
SPA
-4
X
O
C
3
-P
O
S
S
T
AT
US
0
1
2
3
C/
A
A
/L
C/A
A
/
L
C/A
A
/
L
C
/
A
A/L
B
I
T
S
C
O
N
A
UX
CA
R
R
IER
LIN
K
M
GMT
ET
H
E
R
N
E
T
DISK
HD
USB
DF
0
1
280181
1 2
