7-6
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-09
Chapter 7 Cisco ASR 1004 Router Overview and Installation
General Rack Installation Guidelines
Note The Cisco ASR 1004 Router usually ships fully loaded. However, you can remove components from the
chassis to make the chassis lighter for your rack installation.
General Rack Installation Guidelines
When planning your rack installation, consider the following guidelines:
• The Cisco ASR 1004 Router requires a minimum of 4 rack units (7 inches or 17.8 cm) of vertical
rack space. Measure the proposed rack location before mounting the chassis in the rack.
• Before using a particular rack, check for obstructions (such as a power strip) that could impair
rack-mount installation. If a power strip does impair a rack-mount installation, remove the power
strip before installing the chassis, and then replace it after the chassis is installed.
• Allow sufficient clearance around the rack for maintenance. If the rack is mobile, you can push it
back near a wall or cabinet for normal operation and pull it out for maintenance (installing or moving
cards, connecting cables, or replacing or upgrading components). Otherwise, allow 19 inches (48.3
cm) of clearance to remove field-replaceable units.
• Maintain a minimum clearance of 3 inches (7.62 cm) on the front, top, and sides of the chassis for
the cooling air inlet and exhaust ports, respectively. Avoid placing the chassis in an overly congested
rack or directly next to another equipment rack; otherwise, the heated exhaust air from other
equipment can enter the inlet air vents and cause an overtemperature condition inside the router.
Caution To prevent chassis overheating, never install a Cisco ASR 1004 Router in an enclosed room that is not
properly ventilated or air conditioned.
• Always install heavier equipment in the lower half of a rack to maintain a low center of gravity to
prevent the rack from falling over.
• Install and use the cable-management brackets included with the Cisco ASR 1004 Router to keep
cables organized and out of the way of the cards and processors. Ensure that cables from other
equipment already installed in the rack do not impair access to the cards or require you to disconnect
cables unnecessarily to perform equipment maintenance or upgrades.
• Install rack stabilizers (if available) before you mount the chassis.
• Provide an adequate chassis ground (earth) connection for your router chassis.
In addition to the preceding guidelines, review the precautions for avoiding excessive temperature
conditions in the “Site Environmental Requirements” section on page 5-9.
Table 7-1 provides the Cisco ASR 1004 Router dimensions and weight information.
Table 7-1 Cisco ASR 1004 Router Dimensions and Weight
Cisco ASR 1004 Dimensions
Depth 22.50 in. (57.15 cm)
(including card handles, cable-management brackets, power
supply handles).
Height 6.95 in. (17.653cm) (4 rack-mount per EIA RS-310)
