2
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information, see the
monthly What’s
New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be
delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS
version
2.0.
1 Prepare for Installation
This section contains information about tools and parts, warnings, site preparation information, and information for
rack-mount installation and equipment shelf or tabletop installation.
Warning
Only trained and qualified personnel should install, replace, or service this equipment.
Statement 1030
Before beginning this router installation, read the Regulatory Compliance and Safety Information for the Cisco ASR 1000 Series
Aggregation Services Routers document.
Site Preparation and Unpacking
• Lift the router safely out of the packing container.
• Ensure the power service at the site is suitable for the router you are installing.
• Check the packing slip to ensure that all the proper components are present.
• Locate and have accessible the Site Log for recording information about this installation.
Tools and Parts
Use the following list of tools and parts as a checklist for preparing to install the Cisco ASR 1000 Series Aggregation Services
Router:
• Disposable ESD-preventative wrist strap
• AC power cord
• Appropriate cables to connect the router to the network and to the console terminal
• Optional tape measure and level
• Screwdrivers: Number 2 Phillips screwdriver and 3/16-inch flat-blade screwdriver
• Grounding lug and wires
• The rack-mount and cable-management kit:
–
Four 19-inch rack-mount brackets (front and rear rails) and two cable-management brackets
–
Three sets of screws: one set for front rack-mount brackets (black screws), another set for rear rack-mount brackets,
and a set for the cable-management brackets (package with four screws)
Prepare for Equipment Shelf
For a equipment shelf installation, verify the following before installing the router:
• The router is off the floor and has adequate ventilation.
• An adequate chassis ground (earth) connection exists for the router.
• The router needs at last 3 inches (7.62 cm) of clearance at the inlet and exhaust vents (sides of router).
