SignalJ2DirectionDescriptionSignalJ1
ST+
ST-
J2-5
J2-23
——>
——>
Twisted pair no. 7O_TxCE/TxC+
O_TxCE/TxC-
J1-3
J1-16
RD+
RD-
J2-6
J2-24
——>
——>
Twisted pair no. 9O_TxD/RxD+
O_TxD/RxD-
J1-1
J1-14
RS+
RS-
J2-7
J2-25
<——
<——
Twisted pair no. 1I_CTS/RTS+
I_CTS/RTS-
J1-11
J1-10
RT+
RT-
J2-8
J2-26
——>
——>
Twisted pair no. 8O_TxC/RxC+
O_TxC/RxC-
J1-2
J1-15
CS+
CS-
J2-9
J2-27
——>
——>
Twisted pair no. 4O_RTS/CTS+
O_RTS/CTS-
J1-8
J1-9
LL
SC
J2-10
J2-37
——>
—
Twisted pair no.
12
B_LL/LL+
Circuit GND
J1-13
J1-26
DM+
DM-
J2-11
J2-29
——>
——>
Twisted pair no.
10
O_DTR/DSR+
O_DTR/DSR-
J1-7
J1-20
TR+
TR-
J2-12
J2-30
<——
<——
Twisted pair no. 3I_DSR/DTR+
I_DSR/DTR-
J1-12
J1-25
RR+
RR-
J2-13
J2-31
——>
——>
Twisted pair no.
11
B_DCD/DCD+
B_DCD/DCD-
J1-6
J1-19
TT+
TT-
J2-17
J2-35
<——
<——
Twisted pair no. 6I_RxC/TxCE+
I_RxC/TxCE-
J1-4
J1-17
The following table lists the V.35 DTE cable pinouts. Arrows indicate signal direction.
Any pin not referenced is not connected.
Note
Table 52: V.35 DTE Cable Pinouts (34-Pin Male Connector)
SignalJ2DirectionDescriptionSignalJ1
---Local
connections
MODE_1
MODE_0
MODE_DCE
J1-22
J1-23
J1-24
Shield
GND
J2-A—Shield--
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
78
Overview: Cisco ASR 9000 Series Router Shared Port Adapters
4-Port Serial Interface SPA Cables, Connectors, and Pinouts
