Cisco ASR 9001 Hardware Installation Guide

RP Front Panel Indicators
The RP card has eight discrete LED indicators for display of system information.
The following table lists the display definitions of the eight discrete LEDs on the RP front panel as well as
the normal LED states on the power modules (AC or DC) and the fan tray after a successful system startup.
Table 18: RP Discrete LED Display Definitions
DescriptionColorLEDIndicator (Label)
RSP in initializing or
failed state.
RedBi-colorRSP FAIL
RSP is up and running.Green
RSP is normal.Off
LC in initializing or failed
state.
RedBi-colorLC FAIL
LC is up and running.Green
LC is normal.Off
Critical Alarm LED. A
critical alarm has
occurred.
RedSingle colorCritical Alarm (CRIT)
No critical alarm has
occurred.
Off (Default after reset)
Major alarm LED. A
major alarm has occurred.
RedSingle colorMajor Alarm (MAJ)
No major alarm has
occurred.
Off (Default after reset)
Minor alarm LED. A
minor alarm has occurred.
AmberSingle colorMinor Alarm (MIN)
No minor alarm has
occurred.
Off (Default after reset)
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
96
Troubleshooting the Installation
RP Front Panel Indicators

Cisco ASR 9001 Specifications

General

Router Series	ASR 9000 Series
Rack Units	2 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Power Supply	AC or DC
Memory	8 GB
Forwarding Capacity	Up to 80 Gbps
Switching Capacity	160 Gbps
Operating Temperature	0 to 40°C
Weight	24 lb
Redundancy	Power supply
