Cisco ASR 9001 Hardware Installation Guide

Each Cisco ASR 9001 Router is powered by only one type of input: AC or DC. A hybrid (AC+DC) power
configuration is not supported.
Caution
Proper grounding is necessary to avoid damage from lightning and power surges. See NEBS Supplemental
Unit Bonding and Grounding Guidelines, on page 22 for grounding requirements.
Caution
AC Powered Routers
AC power modules operate in the input range of 100 VAC to 240 VAC, 50 to 60 Hz and require a minimum
service of:
•
15 A for operation in North America and Japan
•
10 A for international operation
•
13 A for operation in the UK
Each of the AC power inputs requires a separate dedicated branch circuit. For a list of the nominal and
acceptable value ranges for source AC power, see AC Input Voltage Range, on page 122.
The following table lists the AC-input power cord options, specifications, and Cisco product numbers for the
AC-input power supply modules. This table also references power cord illustrations. For more information
on Cisco product numbers (PIDs) and their detailed description of power cords, refer to Dynamic Configuration
Tool.
Table 2: AC-Input Power Cord Options for ASR 9001 Router
Reference
Illustration
Power Cord RatingLengthPart NumberLocale
Figure 9: AC Power
Cord CAB-AC
15 A, 250 V8.2 feet (2.5 m)CAB-ACUSA
Figure 10: AC
Power Cord
CAB-L620P-C13-JPN
15 A, 250 V8.2 feet (2.5 m)CAB-L620P-C13-JPNJapan
Figure 11: AC
Power Cord
CAB-ACA
10 A, 250 V8.2 feet (2.5 m)CAB-ACAAustralia
Figure 12: AC
Power Cord
CAB-ACI
10 A, 250 V8.2 feet (2.5 m)CAB-ACIItaly
Figure 13: AC
Power Cord
CAB-ACR
10 A, 250 V8.2 feet (2.5 m)CAB-ACRArgentina
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
14
Preparing for Installation
Power Connection Guidelines
