What to Do Next
Figure 32: Installing the Cisco ASR 9001 Router Chassis in a Four-Post Rack
Two rear mounting
brackets on each side to
attach the chassis to the
rear rack posts.
2Three screws on each side
(minimum two) to attach
the chassis to the rack.
1
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
41
Unpacking and Installing the Chassis
Installing the Chassis in a Four-Post Rack
