18-AWG copper wire for the power cord
•
6-AWG or larger copper wire for the ground wire
•
Wire-stripping tools appropriate to the wire that you are using
Before making connections to the Cisco ASR 903 Router as a satellite shelf, ensure that you disconnect
the power at the circuit breaker. Otherwise, severe injury to you or damage to the router may occur.
Caution
This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority
or an electrician if you are uncertain that suitable grounding is available. Statement 1024
Warning
Use copper conductors only. Statement 1025Warning
When installing or replacing the unit, the ground connection must always be made first and disconnected
last. Statement 1046
Warning
This unit is to be installed in a restrictive access location and must be permanently grounded to minimum
6-AWG copper ground wire.
Installing the Chassis Ground
Perform the following procedure to ground the Cisco ASR 903 Router as a satellite shelf using a 2-hole lug
and the corresponding mounting point. Most carriers require a minimum 6-AWG ground connection. Verify
your carrier’s requirements for the ground connection.
SUMMARY STEPS
1.
If your ground wire is insulated, use a wire-stripping tool to strip the ground wire to 0.5 inch ± 0.02 inch
(12.7 mm ±0.5 mm).
2.
Slide the open end of your 2-hole ground lug over the exposed area of the ground wire.
3.
Using a crimping tool (as specified by the ground lug manufacturer), crimp the ground lug to the ground
wire as shown in this figure.
4.
Use a Phillips head screwdriver to attach the 2-hole ground lug and wire assembly to the router with the
2 pan-head Phillips head screws. For a 19-inch EIA rack, attach the 2-hole ground lug to the rear of the
router.
5.
Connect the other end of the ground wire to a suitable grounding point at your site.
Cisco ASR 9000 Series Aggregation Services Router Satellite Systems Installation Guide
30
Installing the Cisco ASR 903 Router as a Satellite Shelf
Installing the Chassis Ground
