Cisco ASR 903 Installation Instructions

Activating the AC Power Supply
SUMMARY STEPS
1.
Plug the power cord into the power supply.
2.
Connect the other end of the power cord to an AC input power source.
3.
Verify power supply operation by checking that the power supply LEDs are in the following states:
4.
If the LEDs indicate a power problem, see the Power Supply LEDs section. For troubleshooting information,
see the Cisco ASR 901 Series Aggregation Services Router Hardware Installation Guide.
5.
If you are installing a redundant power supply, repeat these steps for the second power source.
DETAILED STEPS
Step 1
Plug the power cord into the power supply.
Step 2
Connect the other end of the power cord to an AC input power source.
Step 3
Verify power supply operation by checking that the power supply LEDs are in the following states:
•
INPUT OK LED is green.
•
OUTPUT FAIL LED is green.
Step 4
If the LEDs indicate a power problem, see the Power Supply LEDs section. For troubleshooting information, see the
Cisco ASR 901 Series Aggregation Services Router Hardware Installation Guide.
Step 5
If you are installing a redundant power supply, repeat these steps for the second power source.
If you are installing a redundant AC power supply, ensure that each power supply is connected to a separate power source
in order to prevent power loss in the event of a power failure.
Removing and Replacing the AC Power Supply
The Cisco ASR 903 power supplies are hot-swappable. If you have installed redundant power supply
modules, you can replace a single power supply without interrupting power to the router.
Note
When you install the unit, the ground connection must always be made first and disconnected last. Statement
1046
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning
Cisco ASR 9000 Series Aggregation Services Router Satellite Systems Installation Guide
51
Installing the Cisco ASR 903 Router as a Satellite Shelf
Removing and Replacing the AC Power Supply

Cisco ASR 903 Specifications

General

Form Factor	Modular
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% non-condensing
Redundancy	Yes, redundant power supplies and route processors
Operating System	Cisco IOS XE
Power Supply	AC or DC
Switching Capacity	240 Gbps
Operating Temperature	-40°C to 65°C (-40°F to 149°F)
MTBF	200, 000 hours
Supported Protocols	IPv4, IPv6, MPLS, L2VPN, L3VPN
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, T1/E1
