Connecting a Management Ethernet Cable
When using the Ethernet Management port in the default mode (speed-auto and duplex-auto) the port operates
in auto-MDI/MDI-X mode. The port automatically provides the correct signal connectivity through the
Auto-MDI/MDI-X feature. The port automatically senses a crossover or straight-through cable and adapts to
it.
However, when the Ethernet Management port is configured to a fixed speed (10 or 100 Mbps) through
command-line interface (CLI) commands, the port is forced to MDI mode.
When in a fixed-speed configuration and MDI mode:
•
Use a crossover cable to connect to an MDI port.
•
Use a straight-through cable to connect to an MDI-X port.
The intra-building port(s) of the equipment or subassembly must not be metallically connected to interfaces
that connect to the OSP or its wiring. These interfaces are designed for use as intra-building interfaces
only (Type 2 or Type 4 ports as described in GR-1089-CORE) and require isolation from the exposed
OSP cabling. The addition of Primary Protectors is not sufficient protection in order to connect these
interfaces metallically to OSP wiring. Statement 7005
Warning
Installing and Removing SFP and XFP Modules
The Cisco ASR 903 Router as a satellite shelf supports a variety of SFP and XFP modules, including optical
and Ethernet modules. For information on how to install and remove SFP and XFP modules, see the
documentation for the SFP or XFP module at:
http://www.cisco.com/en/US/partner/products/hw/modules/ps5455/prod_installation_guides_list.html
For information about inspecting and cleaning fiber-optic connections, see:
http://www.cisco.com/en/US/partner/tech/tk482/tk876/technologies_white_paper09186a0080254eba.shtml
Connecting a USB Flash Device
To connect a USB flash device to the Cisco ASR 903 Router as a satellite shelf, insert the memory stick in
the USB port labeled MEM. The Flash memory module can be inserted in only one way, and can be inserted
or removed regardless of whether the router is powered up or not.
Cisco ASR 9000 Series Aggregation Services Router Satellite Systems Installation Guide
63
Installing the Cisco ASR 903 Router as a Satellite Shelf
Connecting a Management Ethernet Cable
