Number 1 and Number 2 Phillips-head screwdrivers
•
Flat-blade screwdrivers: Small 3/16-inch (0.476 cm) and medium 1/4-inch (0.625 cm):
◦
To install or remove modules
◦
To remove the cover if you are upgrading the memory or other components
•
#12-24 pan-head screws to secure the router to the equipment rack
•
Cables for connecting to the WAN and LAN ports (depending on the configuration)
For more information on cable specifications, see the Cisco ASR 903 Series Aggregation Services Router
Hardware Installation Guide.
Note
•
Ethernet hub or switch or PC with a network interface card for connecting to the Ethernet ports
•
Console terminal (an ASCII terminal or a PC running terminal emulation software) that is configured
for 9600 baud, 8 data bits, no parity, and 2 stop bits
•
Console cable for connecting to the console port
•
(Optional) Modem for connecting to the auxiliary port for remote administrative access
•
Auxiliary cable for connecting to the auxiliary port (you can supply this cable or order one)
•
Ratcheting torque screwdriver with a Phillips head that exerts up to 30 pound-force per square inch
(lbf/sq in) of pressure
•
Crimping tool as specified by the ground lug manufacturer
•
18-AWG copper wire for the power cord
•
Wire-stripping tools for stripping both 6-AWG and 18-AWG wire
•
Tape measure and level
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
Unpacking and Verifying the Shipped Contents
When you receive your chassis, perform the following steps and use the Shipping Contents Checklist:
1
Inspect the box for any shipping damage. If there is obvious physical damage, contact your Cisco service
representative.
2
Unpack the Cisco ASR 903 Router satellite shelf.
3
Perform a visual inspection of the chassis.
4
Use this table to check the contents of the Cisco ASR 903 Router as a satellite shelf shipping container.
Do not discard the shipping container. You will need the container if you move or ship the Cisco ASR
903 Router as a satellite shelf in the future.
Cisco ASR 9000 Series Aggregation Services Router Satellite Systems Installation Guide
21
Installing the Cisco ASR 903 Router as a Satellite Shelf
Unpacking and Verifying the Shipped Contents
