Connecting to the Auxiliary Port
When a modem is connected to the auxiliary port, a remote user can dial in to the router and configure it. Use
a light blue console cable and the DB-9-to-DB-25 connector adapter.
The console cable and DB-9-to-DB-25 connector are not included with the Cisco ASR 903 Router as a
satellite shelf; they are ordered separately.
Note
To connect a modem to the router, follow these steps:
SUMMARY STEPS
1.
Connect the RJ-45 end of the adapter cable to the black AUX port on the router, as shown in the figure.
2.
Connect the DB-9 end of the console cable to the DB-9 end of the modem adapter.
3.
Connect the DB-25 end of the modem adapter to the modem.
4.
Make sure that your modem and the router auxiliary port are configured for the same transmission speed
(up to 115200 bps is supported) and for mode control with data carrier detect (DCD) and data terminal
ready (DTR) operations.
Cisco ASR 9000 Series Aggregation Services Router Satellite Systems Installation Guide
61
Installing the Cisco ASR 903 Router as a Satellite Shelf
Connecting to the Auxiliary Port

Cisco ASR 903 Specifications

General

Form Factor	Modular
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% non-condensing
Redundancy	Yes, redundant power supplies and route processors
Operating System	Cisco IOS XE
Power Supply	AC or DC
Switching Capacity	240 Gbps
Operating Temperature	-40°C to 65°C (-40°F to 149°F)
MTBF	200, 000 hours
Supported Protocols	IPv4, IPv6, MPLS, L2VPN, L3VPN
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, T1/E1
