Cisco ASR 903 Installation Instructions

SUMMARY STEPS
1.
Unzip the file Cisco_usbconsole_driver_X_X.zip (where X is a revision number).
2.
If using 32-bit Windows XP double-click the file setup.exe from the Windows_32 folder, or if using 64-bit
Windows XP double-click the file setup(x64).exe from the Windows_64 folder.
3.
The Cisco Virtual Com InstallShield Wizard begins. Click Next.
4.
The Ready to Install the Program window appears, Click Install.
5.
The InstallShield Wizard Completed window appears. Click Finish.
6.
Connect the USB cable to the PC and router USB console ports. The EN LED for the USB console port
turns green, and within a few moments the Found New Hardware Wizard appears. Following the instructions
to complete the installation of the driver.
7.
The USB console is ready for use.
DETAILED STEPS
Step 1
Unzip the file Cisco_usbconsole_driver_X_X.zip (where X is a revision number).
Step 2
If using 32-bit Windows XP double-click the file setup.exe from the Windows_32 folder, or if using 64-bit Windows
XP double-click the file setup(x64).exe from the Windows_64 folder.
Step 3
The Cisco Virtual Com InstallShield Wizard begins. Click Next.
Step 4
The Ready to Install the Program window appears, Click Install.
Step 5
The InstallShield Wizard Completed window appears. Click Finish.
Step 6
Connect the USB cable to the PC and router USB console ports. The EN LED for the USB console port turns green, and
within a few moments the Found New Hardware Wizard appears. Following the instructions to complete the installation
of the driver.
Step 7
The USB console is ready for use.
Installing the Cisco Microsoft Windows 2000 USB Driver
SUMMARY STEPS
1.
Obtain the file Cisco_usbconsole_driver.zip from the Cisco.com website and unzip it.
2.
Double-click the file setup.exe.
3.
The Cisco Virtual Com InstallShield Wizard begins. Click Next.
4.
The Ready to Install the Program window appears, Click Install.
5.
The InstallShield Wizard Completed window appears. Click Finish.
6.
Connect the USB cable to the PC and router USB console ports. The EN LED for the USB console port
turns green, and within a few moments a series of Found New Hardware Wizard windows appear. Following
the instructions to complete the installation of the driver.
7.
The USB console is ready for use.
Cisco ASR 9000 Series Aggregation Services Router Satellite Systems Installation Guide
57
Installing the Cisco ASR 903 Router as a Satellite Shelf
Connecting Console Cables

Cisco ASR 903 Specifications

General

Form Factor	Modular
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% non-condensing
Redundancy	Yes, redundant power supplies and route processors
Operating System	Cisco IOS XE
Power Supply	AC or DC
Switching Capacity	240 Gbps
Operating Temperature	-40°C to 65°C (-40°F to 149°F)
MTBF	200, 000 hours
Supported Protocols	IPv4, IPv6, MPLS, L2VPN, L3VPN
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, T1/E1
