DescriptionField
Long timeout between entering digits when dialing. The interdigit timer
values are used as defaults when dialing. The Interdigit_Long_Timer
is used after any one digit, if all valid matching sequences in the dial
plan are incomplete as dialed. Range: 064 seconds.
Default setting: 10
Interdigit Long Timer.
Short timeout between entering digits when dialing. The
Interdigit_Short_Timer is used after any one digit, if at least one
matching sequence is complete as dialed, but more dialed digits would
match other as yet incomplete sequences. Range: 064 seconds.
Default setting: 3
Interdigit Short Timer.
Delay in seconds after caller hangs up when the ATA starts removing
the tip-and-ring voltage to the attached equipment of the called party.
The range is 0255 seconds. This feature is generally used for answer
supervision on the caller side to signal to the attached equipment when
the call has been connected (remote end has answered) or disconnected
(remote end has hung up) This feature should be disabled for the called
party (in other words, by using the same polarity for connected and idle
state) and the CPC feature should be used instead.
Without CPC enabled, reorder tone is played after a configurable delay.
If CPC is enabled, dial tone will be played when tip-to-ring voltage is
restored. Resolution is 1 second.
Default setting: 2
CPC Delay.
Duration in seconds for which the tip-to-ring voltage is removed after
the caller hangs up. After that, tip-to-ring voltage is restored and the
dial tone applies if the attached equipment is still off-hook. CPC is
disabled if this value is set to 0. Range: 0 to 1.000 second. Resolution
is 0.001 second.
Default setting: 0.5
CPC Duration.
Vertical Service Activation Codes
Vertical Service Activation Codes are automatically appended to the dial-plan. There is no need to include
them in dial-plan, although no harm is done if they are included.
Table 43: Vertical Service Activation Codes
DescriptionField
Call Return Code This code calls the last caller.
Default setting: *69
Call Return Code.
Cisco ATA 191 and ATA 192 Analog Telephone Adapter Administration Guide for Multiplatform Firmware
63
Voice Settings Configuration
Vertical Service Activation Codes
