DescriptionField
To enable local detection of DTMF ABCD, select
Yes. Otherwise, select No. Default setting: Yes
This setting has no effect if DTMF Tx Method is
INFO; ABCD is always sent OOB regardless in this
setting.
Detect ABCD:
To enable local playback of OOB DTMF ABCD,
select Yes. Otherwise, select No. Default setting: Yes
Playback ABCD:
Your choices are:
•
Bellcore (N.Amer,China): CID, CIDCW, and
VMWI. FSK sent after first ring (same as ETSI
FSK sent after first ring) (no polarity reversal
or DTAS).
•
DTMF (Finland, Sweden): CID only. DTMF
sent after polarity reversal (and no DTAS) and
before first ring.
•
DTMF (Denmark): CID only. DTMF sent
before first ring with no polarity reversal and
no DTAS.
•
ETSI DTMF: CID only. DTMF sent after DTAS
(and no polarity reversal) and before first ring.
•
ETSI DTMF With PR: CID only. DTMF sent
after polarity reversal and DTAS and before
first ring.
•
ETSI DTMF After Ring: CID only. DTMF sent
after first ring (no polarity reversal or DTAS).
•
ETSI FSK: CID, CIDCW, and VMWI. FSK
sent after DTAS (but no polarity reversal) and
before first ring. Waits for ACK from a device
after DTAS for CIDCW.
•
ETSI FSK With PR (UK): CID, CIDCW, and
VMWI. FSK is sent after polarity reversal and
DTAS and before first ring. Waits for ACK
from a device after DTAS for CIDCW. Polarity
reversal is applied only if equipment is on hook.
•
DTMF (Denmark) with PR: CID only. DTMF
sent after polarity reversal (and no DTAS) and
before first ring.
Default setting: Bellcore(N.Amer, China)
Caller ID Method:
The choices are from 1 to 8. Default setting: 3FXS Port Power Limit:
Cisco ATA 191 and ATA 192 Analog Telephone Adapter Administration Guide for Multiplatform Firmware
71
Voice Settings Configuration
