Cisco Catalyst 2900 Series XL Hardware Installation Guide

1-13
Catalyst 2900 Series XL Hardware Installation Guide
78-6461-03
Chapter 1 Product Overview
100BASE-FX Ports
Port LEDs and Modes
Each of the 10/100, 100BASE-FX, and LRE ports and module slots have a port
LED. These port LEDs, as a group or individually, display information about the
switch and about the individual ports. The port modes (Table 1-5 and Table 1-6)
determine the type of information displayed.
To select or change a mode, press the Mode button until the desired mode is
highlighted. When you change port modes, the meaning of the port LED colors
also changes. Table 1-7and Table 1-8 list the port LED colors.
Solid amber RPS is connected but not functioning properly.
• The RPS could be in standby mode. Pressing the Standby/Active button the
RPS puts it in Active mode, and the LED should turn green.
• One of the power supplies in the RPS could be powered down.
• A fan in the RPS might have failed.
Blinking amber Internal power supply of the switch is down, and redundancy is lost. The switch is
operating on the RPS.
Table 1-4 RPS LED on the Catalyst 2912 LRE XL and 2924 LRE XL Switches (continued)
Color RPS Status
Table 1-5 Port Mode LEDs on the Catalyst 2912 XL, 2924C XL, 2924 XL, 2924MF XL, and 2924M XL
Switches
Mode LED Port Mode Description
STAT Port status The port status. This is the default mode.
UTL Switch utilization The current bandwidth in use by the switch. (See Figure 1-7.)
FDUP Port duplex mode The port duplex mode: full duplex or half duplex.
100 Port speed The port operating speed: 10, 100, or 1000 Mbps.
