Cisco Catalyst 2900 Series XL Hardware Installation Guide

Chapter 2 Installation
Installing the Switch on a Wall
2-22
Catalyst 2900 Series XL Hardware Installation Guide
78-6461-03
Installing the Switch on a Wall
To attach the switch to a wall, follow the procedures in this section:
• Attaching the brackets to the switch
• Attaching the switch to a wall
Note To mount a Catalyst 2912 LRE XL or 2924 LRE XL switch on a
wall,youneedtoobtaintwospecialwall-mountbrackets(Ciscopart
number wallmount-1ru=). To order these brackets, contact your
Cisco sales representative.
Attaching the Brackets to the Switch
The bracket orientation and the screws you use depend on whether you are
attaching the brackets for parallel or vertical wall-mounting. Use two of the
supplied screws to attach each bracket, according to the following guidelines:
• For parallel wall-mounting, use the supplied Phillips truss-head screws to
attach the short side of the bracket to the switch.
• For vertical wall-mounting, use the supplied Phillips flat-head screws to
attach the long side of the bracket to the switch.
Note The Catalyst 2912 LRE XL and 2924 LRE XL switches cannot be mounted
vertically on a wall.
Figure 2-13 and Figure 2-13 show how to attach the brackets to one side of the
switch. Follow the same steps to attach the second bracket to the opposite side of
the switch.
