Chapter 2 Installation
Installing the Switch in a Rack
2-10
Catalyst 2900 Series XL Hardware Installation Guide
78-6461-03
To install the switch in a 19-, 23- or 24-inch standard rack, follow the instructions
described in these procedures:
Removing Screws from the Switch sectiononpage2-10
Attaching the Brackets to a Catalyst 2912 XL, 2924C XL, 2924 XL, 2912MF
XL, or 2924M XL Switch section on page 2-11
Attaching the Brackets to a Catalyst 2912 LRE XL or 2924 LRE XL Switch
sectiononpage2-17
Mounting the Switch in a Rack sectiononpage2-19
Attaching the Optional Cable Guide sectiononpage2-20
Removing Screws from the Switch
Ifyouplantoinstalltheswitchinarack,youmustfirstremovescrewsinthe
switch chassis so that mounting brackets can be attached. Figure 2-3 shows how
to remove the chassis screws in a fixed-port and a modular port switch.
Figure 2-3 Removing Screws from the Switch
47292
22X22X
2
3X
2
4X
S
E
R
IE
S
C
a
t
a
ly
s
t 2
9
0
0
X
L
Fixed-port
Catalyst 2900 series XL
Modular
Catalyst 2900 series XL
S
E
R
I
E
S
C
a
ta
ly
s
t 2
9
0
0
X
L
