Chapter 2 Installation
Installing the Switch in a Rack
Figure 2-1 Mounting Bracket Points for Catalyst 2912 XL, 2924C XL, 2924 XL,
2912MF XL, or 2924M XL Switches
Figure 2-2 Mounting Brackets Points for Catalyst 2912 LRE XL and
2924 LRE XL Switches
47307
19" rack
mount point
19" rack
mount point
24" rack
mount point
24" rack
mount point
23" rack
mount point
23" rack
mount point
54725
19" rack
mount point
19" rack
mount point
24" rack
mount point
24" rack
mount point
23" rack
mount point
23" rack
mount point
