Cisco Catalyst 2960-CX User Manual

System LED
System StatusColor
System is not powered on.Off
System is operating normally.Green
System is receiving power but is not operating
properly.
Amber
Modes for Port LEDs
The port LEDs, as a group or individually, display information about the switch and about the individual
ports.
DescriptionPort ModeLED
The port status. This is the default mode.Port statusSTAT
The port operating speed: 10, 100, or 1000
Mb/s.
Port speedSPEED
The PoE status.PoE port powerPoE
PoE LED
Even if the PoE mode is not selected, the LED shows PoE problems when they are detected. The PoE LED
is only on the switches that support PoE.
DescriptionColor
PoE is not enabled.Off
PoE is enabled. Ports are functioning correctly.Green
•
PoE mode is not selected
•
At least one of the 10/100 or 10/100/100 PoE ports has been denied
power
•
At least one of the ports has a PoE fault
Blinking amber
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
7
Product Overview
LEDs

Cisco Catalyst 2960-CX Specifications

General

PoE	No
DRAM	512 MB
MAC Address Table Size	16, 000 entries
Stacking	No
Model	Cisco Catalyst 2960-CX
Ports	8 x 10/100/1000 Ethernet ports
Uplink Interfaces	2 x 1G SFP
Power Input	100 to 240 VAC
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25°C to 70°C (-13°F to 158°F)
Power Consumption	15W
Relative Humidity	10 to 95% noncondensing
