Cisco Catalyst 2960-CX User Manual

To prevent airflow restriction, allow clearance around the ventilation openings to be at least: 3 in. (7.6 cm) Statement
1076
Figure 12: Mounting the Switch Under a Desk or Shelf
Wall-Mounting
Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct hardware
or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
Statement 378
Do not wall-mount the switch with its front panel facing up. Following safety regulations, wall-mount the
switch with its front panel facing down or to the side to prevent airflow restriction and to provide easier
access to the cables
Caution
Step 1
Locate the screw template. The template is used to align the mounting screw holes.
Step 2
Position the screw template so that the edge that is marked as CABLE SIDE ENTRY faces toward the floor.
For the best support of the switch and cables, make sure that you attach the switch securely to a wall stud or to
a firmly attached plywood mounting backboard
Note
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
21
Switch Installation
On a Desk, Shelf, or Wall (with Mounting Screws)

Cisco Catalyst 2960-CX Specifications

General

PoE	No
DRAM	512 MB
MAC Address Table Size	16, 000 entries
Stacking	No
Model	Cisco Catalyst 2960-CX
Ports	8 x 10/100/1000 Ethernet ports
Uplink Interfaces	2 x 1G SFP
Power Input	100 to 240 VAC
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25°C to 70°C (-13°F to 158°F)
Power Consumption	15W
Relative Humidity	10 to 95% noncondensing
