This is only required if you are not installing the wall-mount brackets.Note
Figure 35: Using the Washer
Washer1
Step 2
Use the supplied number-10 pan-head screws to attach the cable guard to the switch.
Figure 36: Attaching the Cable Guard to the Switch
Two number-10 Phillips pan-head screws3Switch1
Cable Guard2
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
40
Switch Installation
Installing the Cable Guard (Optional)

Cisco Catalyst 2960-CX Specifications

General

PoE	No
DRAM	512 MB
MAC Address Table Size	16, 000 entries
Stacking	No
Model	Cisco Catalyst 2960-CX
Ports	8 x 10/100/1000 Ethernet ports
Uplink Interfaces	2 x 1G SFP
Power Input	100 to 240 VAC
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25°C to 70°C (-13°F to 158°F)
Power Consumption	15W
Relative Humidity	10 to 95% noncondensing
