Cisco Catalyst 2960-X Configuration Guide

PurposeCommand or Action
• power inline police action log—Generates a syslog message
while still providing power to the port.
If you do not enter the action log keywords, the default action shuts
down the port and puts the port in the error-disabled state.
Returns to global configuration mode.exit
Example:
Switch(config-if)# exit
Step 4
(Optional) Enables error recovery from the PoE error-disabled state,
and configures the PoE recover mechanism variables.
Use one of the following:
Step 5
•
errdisable detect cause inline-power
By default, the recovery interval is 300 seconds.
•
errdisable recovery cause inline-power
For interval interval, specifies the time in seconds to recover from the
error-disabled state. The range is 30 to 86400.
•
errdisable recovery interval interval
Example:
Switch(config)# errdisable detect cause
inline-power
Switch(config)# errdisable recovery cause
inline-power
Switch(config)# errdisable recovery
interval 100
Returns to privileged EXEC mode.exit
Example:
Switch(config)# exit
Step 6
Displays the power monitoring status, and verify the error recovery
settings.
Use one of the following:
Step 7
•
show power inline police
•
show errdisable recovery
Example:
Switch# show power inline police
Switch# show errdisable recovery
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
94 OL-29420-01
Configuring PoE
Configuring Power Policing

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
